Description
Features
- Compact design for installation convenience: just 33 cm by 33 cm, and less than 13.5 cm high (Approx. 13" by 13", and 5.3" in height)
- Compatible with HDMI standards (4K/60P 4:4:4) and HDCP 2.2
- 4K input specs: Supports 4K/60p, 4:4:4/36bit, 4K/60p 4:2:2/36bit, and 4K/24p 4:4:4/36bit signals - for more vivid colors and subtle gradations
- 4K resolution (3840 x 2160) achieved
- Connectors: PC in, HDMI 1 with HDCP2.2 support, HDMI 2, USB Mini B, Trigger (12 V), USB Mini A (1.5 A power supply), and RS-232
- 0.47-inch DMD for bright high-definition 4k images
- Dynamic contrast ratio: 100,000:1
- Brightness: 2,000 lm
- 100% coverage of Rec. 709 gamut
- Wide lens shift function: +/-60% vertical, +/-23% horizontal
- 1.6x high-resolution lens
- HDR (high dynamic range) for more realistic, dynamic images
- HDCP2.2 compatibility with HDMI 1 terminal to support video-streaming services and copyright-protected content including UHD BD discs
- Available in 2 colors (black and white)
-
LX-UH1B
- Device
- 0.47" DMD (1920 x 1080)
- Resolution
- 3840 x 2160
- Lens shift function
- +/-60% vertical & +/-23% horizontal, motorized
- Light source lamp
- NSH 240 W
- Lamp life
- Approx. 4,000 hours in normal mode, 10,000 hours in eco mode
- Brightness
- 2,000 lm
- Contrast Ratio
- Dynamic: 100,000:1
- Video input terminals (back panel)
- PC
- 1 (D-sub 15pin)
- Control terminals
- RS232C
- 1 (D-sub 9-pin)
General
- Noise level
- 29 dB (Eco)/ 33 dB (Normal)
- Power requirement
- AC110 V-240 V, 50/60 Hz
- Dimensions: W x H x D, mm
- 333 x 135 x 331.5 mm
- Dimensions: W x H x D, inches
- 13-1/8 x 5-5/16 x 13-1/16
- Weight, kg
- 4.8
- Weight, lbs
- 10.56
